COBB Adjustable Internal Wastegate Bracket
COBB Tuning is proud to announce the availability of an innovative new pair of Internal Wastegate (IWG) Brackets for Subaru and MAZDASPEED vehicles in short and long bracket styles. The COBB Tuning Adjustable IWG Bracket is the first of its kind, and the most versatile and reliable way to keep a turbocharger’s internal wastegate closed when using an external wastegate setup. The Adjustable IWG Bracket can be installed quickly, adjusted for perfect fitment on many different turbos, and can be removed just as easily to return a turbo to its original configuration.
The COBB Adjustable IWG Bracket replaces the internal wastegate actuator and locks the wastegate in a fully closed position. This is a superior solution to welding the wastegate door closed, which is a time-consuming, expensive and irreversible process. The COBB Adjustable IWG Bracket is easy to install and bolts into place and adjusts quickly using simple hand tools.
Not all turbos are made exactly the same, and there can be variations in housings, center cartridges, clocking, etc. A single position internal wastegate bracket may not accommodate these variations and fail to close the wastegate completely, which will result in poor turbo response and lower maximum boost. The COBB Adjustable IWG Bracket takes the worry of turbo-component variance out of the equation and allows proper adjustment, every time, on a variety of different turbos that a non-adjustable internal wastegate bracket simply cannot match.
The COBB Adjustable IWG Bracket’s advantage lies in its unique adjustable rod-end linkage. The turnbuckle center section features right-hand and left-hand threads to make adjustment as easy as rotating it one direction or the other to shorten or lengthen it. The rod-end linkage and through-bolt allow high misalignment for maximum adjustability. The bracket itself is made from a single piece of 11-Gauge steel and incorporates slotted bolt holes for additional adjustability and turbo compatibility. The custom spade-bolt that connects to the wastegate arm, the bracket, and the turnbuckle are black zinc coated for an attractive finish that is corrosion resistant. All hardware for install is included in this kit.
The COBB Tuning Adjustable IWG Bracket offers maximum turbo compatibility, simple installation and is easily adjustable to ensure complete wastegate closure to get the maximum performance from your specific setup. In the familiar words of our dads, “Make sure you shut the damned door!”
Part #: 512273 and 512274 MSRP: $39.00 Vehicle Applications: This is a preliminary list. Additional applications will be listed as confirmed |
|||
Part # | Make | Model | Years |
512274 | Subaru | STI | 2008-2012 |
512273 | Subaru | STI | 2004-2007 |
512273 | Subaru | WRX | 2009-2012 |
512274 | Subaru | WRX | 2002-2008 |
512274 | Subaru | 2.5GT | 2010-2011 |
512273 | Subaru | Forester XT | 2004-2007 |
512273 | Mazda | MAZDASPEED3 | 2007-2012 |
512273 | Mazda | MAZDASPEED6 | 2006-2007 |
512273 | Mazda | Mazda3 MPS | 2007-2011 |
512273 | Mazda | Mazda6 MPS | 2004-2006 |
Turbo Applications This is a preliminary list. Additional applications will be listed as confirmed |
||
Part # | Manufacturer | Model |
512273 | APS | SR20 |
512273 | Blouch | 20g, 20g-XT, 20g-XTR |
512273 | Blouch | Dominator 1.5, Dominator 3.0R |
512273 | BorgWarner | K04 |
512273 | Forced Performance | Old FP Green |
512273 | Garrett | All T25 flanged internally gated turbos |
512273 | IHI | VF39, VF43 |
512274 | IHI | VF39, VF43 |
512273 | Turbochargers.com | 18G |
512273 | Mitsubishi | TD04 |
Will this bracket work for the aps sr30 turbo? You guys put down aps sr20 but thought you might be referring to the sr30. Let me know thanks. And do I need the long or short one
It hasn’t been tested on that turbo yet, but check out this link for our fitment program: https://forums.cobbtuning.com/forums/showthread.php?73036-Adjustable-IWG-Bracket-Confirm-Fitment-Get-a-Shirt!
Ian@COBB
i had a question for: COBB Adjustable Internal Wastegate Bracket
I have a Deadbolt SZ55. I know they are not in manufacture anymore. but i wanted to change it from internal wastegate to external.
I believe this is the first step to make my car from internal wastegate to external.
Please let me know so i may purchase this bracket.
Thank you.
That is exactly correct! This is a great solution due to the adjustability to ensure a properly closed wastegate, as well as being totally reversible.
Ian@COBB
